 / Maniron 80-520/694-2700MHz RF Diplexer Combiner with Low PIM -155dBc

RF Dual band Combiner
RF Dual band Combiner RF Dual band Combiner RF Dual band Combiner

Maniron 80-520/694-2700MHz RF Diplexer Combiner with Low PIM -155dBc

This Diplexer covers frequency 80-520/694-2700MHz for IBS DAS, with low PIM-155dBc.It's easy for installation.

  • Item NO.:

    MDC-2700-4F-155S

  • Product Orgin:

    China

  • Brand:

    Maniron

  • Shipping Port:

    Shanghai/Guangzhou/Shenzhen
Inquiry now
  • Products Details

Product Name

80-520/694-2700MHz Diplexer is for outdoor with high performance.

Product Features

◆Compact, low weight

◆Low PIM

◆High reliability

◆Simple installation

Technical &Mechanical Specifications

                  Product Name

                                                   Dual Band Combiner

Frequency Band(MHz)

CH1:80 to520MHz CH2:694to 2700MHz





VSWR
≤1.3
Isolation
≥40dB
Insertion Loss(dB)

≤0.5dB

Connectors type 4.3-10 female
Impedance
 50 Ohm
Power/Avg 200W
PIM(dBc)
≤-155@2×43dBm
IP Rate
 65
Operating Temp. (℃)
 -20~+55

Images

80-520/694-2700MHz diplexer
