RF Duplexer Combiner frequency 1710-1980MHz with N female

The rf combiner/rf diplexer covers from 1710-1980MHz,in low PIM -160dBc.

  • Item NO.:

    MNL-DP-1718-NF

  • Product Orgin:

    China

  • Brand:

    Maniron

  • Shipping Port:

    Shanghai/Shenzhen

  • Color:

    Black
Inquiry now
  • Products Details

Product Name

1710-1980MHz Low PIM RF Diplexer/Dual Band Combiner


Product Features

◆Compact, Low Weight

◆ Contain 2G/3G/4G/5G

◆Low Passive Inter-modulation  -155dBc

◆High Reliability

◆ Simple Installation

This combiner,rf diplexer/duplexercovers frequency 698-2700MHz,it is in low PIM -160dBc.


Technical &Mechanical Specifications

Electrical Specifications

Port

Band 1

Band 2

Frequency Range

1805-1945MHz

1710-2700MHz

VSWR

1.3

1.3

Passband Loss

≤1.5dB

≤1.5dB

Power Handling

300W

300W

Rejection

≥60dB

≥60dB


Amplitude ripple across any 1.23 MHz channel



1.0 dB p-p



1.0 dB p-p



Passband Group Delay Variation



80ns


Impedance

50Ω
