4310 Female Crimp Connector For LMR240 Cable

4310 FEMALE CRIMP FOR LMR240 CABLE has low loss and good performance, characteristic impedance is 50ohm. The characteristic of adapter is in wide working frequency, reliable connection,great vibration performance.

Item NO.:
MNC-4K-LMR240
Product Orgin:
China
Brand:
Maniron
Shipping Port:
Shanghai/Ningbo/Shenzhen

Inquiry now

Products Details

Product Name

4310 Female CRIMP connector series is designed to meet the rising performance needs of mobile network equipment e.g. to connect with LMR240 CABLE.The small size and low weight of these connectors do justice to the miniaturization of mobile radio network components.

Product Features

4310 Female Crimp Connector For LMR240 Cable is Low VSWR and excellent impedance matching

Technical &Mechanical Specifications

Model No.	MNC-4K-LMR240
Interface	According to IEC 60169-4 IEC 60169-16
Electrical	Characteristic Impedance	50 ohm
	Frequency Range	DC-3GHz
	Dielectric Withstanding Voltage	≥2500V RMS,50Hz,at sea level
	Dielectric Resistance	≥5000M ohms
	Contact Resistance	Center Contact≤1.0M ohms Outer Contact≤1.0M ohms
	VSWR	≤1.20
	Performance	Good
	Insertion Loss	≤0.5dB
Mechanical	Durability	Mating cycles≥500
Material and plating	Body	Brass Ni
	Insulator	PTFE
	Center Conductor	Brass Au
	Temp	-40~+85

Product picture

4310FEMALE CRIMP FOR LMR240 CABLE

OUR SERVICES

1. Professional skills support for all kinds of adapters and connectors
2. OEM services is available.
3. 24 hours you can contact our salesman and engineer.
4. We will try our best to provide support whatever you need and we can do.

NOTE:All the specifications can be changed as customer's requirment. Our company has a variety of products to choose

Leave Message

If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.

Subject : 4310 Female Crimp Connector For LMR240 Cable
Im interested in your "4310 Female Crimp Connector For LMR240 Cable", please inform me more detailed product information and price. Thankyou!
