N Male Solder Type Connector for RG402/141 Cable

N Male Solder Type Connector for RG402/141 Cable

N Male Solder Type Connector has Low PIM and need to solder with RG402/141 cable, characteristic impedance is 50ohm. The characteristic of connector is in wide working frequency, reliable connection,great vibration performance.

Item NO.:
MNC-NM-RG402/141
Product Orgin:
China
Shipping Port:
Shanghai/Ningbo/Shenzhen

Inquiry now

Products Details

Product Name

N Male Solder Type Connector for RG402/141 Cable series is designed to meet the rising performance needs of mobile network equipment e.g. to connect the RRU to the antenna.The small size and low weight of these connectors do justice to the miniaturization of mobile radio network components.Three different coupling mechanisms of the plug connectors screw,quick-lock/push-pull and hand-screw types are mateable with all jack connectors.

Product Features

N Male Solder Type Connector for RG402/141 Cable is Low VSWR and excellent impedance matching

Technical &Mechanical Specifications

Model No.	MNC-NM-RG402/141
Interface	According to IEC 61169-54
Electrical	Characteristic Impedance	50 ohm
	Frequency Range	DC-3GHz
	Dielectric Withstanding Voltage	≥1000V RMS,50Hz,at sea level
	Dielectric Resistance	≥5000M ohms
	Contact Resistance	Center Contact≤1.0M ohms Outer Contact≤1.0M ohms
	VSWR	≤1.15
	PIM	≤-150dBc
	Insertion Loss	≤0.5dB
Mechanical	Durability	Mating cycles≥500
Material and plating	Body	Brass or Tri-Alloy
	Insulator	PTFE
	Center Conductor	Brass Ag
	Coupling Nut	Brassi Ni
Temp	-40~+85

Mechanical Drawing (mm)

N Male Solder Type Connector for RG402/141 Cable

OUR SERVICES

1. Professional skills support for N Male Solder Type Connector for RG402/141 Cable
2. OEM services is available.
3. 24 hours you can contact our salesman and engineer.
4. We will try our best to provide support whatever you need and we can do.

NOTE:All the specifications can be changed as customer's requirment. Our company has a variety of products to choose
