DC-6GHz DIN Male to N Female RF Adaptor with Low PIM -160dBC

RF Adapter DIN-Male to N-Female Straight covers frequency from DC to 6GHz,it has low PIM -160dBC

Item NO.:
MNA-7/16J-NK
Product Orgin:
China
Brand:
Maniron
Shipping Port:
Shanghai/Shengzhen/Ningbo
Color:
Silver

Inquiry now

Products Details

Product Name

RF Adaptor DIN Male to N-Female is easily installation with Low PIM -160dBc,low VSWR

Technical &Mechanical Specifications

Model No.	MNA-7/16J-NK
Electrical	Characteristic Impedance	50 ohm
	Frequency Range	DC-6GHz
	Dielectric Withstanding Voltage	≥2500V RMS,50Hz,at sea level
	Dielectric Resistance	≥5000MΩ
	Contact Resistance	Center Contact≤1.0M ohms Outer Contact≤1.0M ohms
	VSWR	≤1.10
	PIM	≤-160dBc
	Mechanical	Durability	Mating cycles≥500
Material and plating	Body	Brass or Tri-Alloy
	Insulator	PTFE
	Center Conductor	Tin-Phosphor bronze Ag
	Temp	-40~+85

Product picture

OUR SERVICES

1. Professional skills support for RF Adaptor
2. OEM/ODM services is available.
3. 24 hours you can contact our salesman and engineer.
4. We will try our best to provide support whatever you need and we can do.

NOTE:All the specifications can be changed as customer's requirment. Our company has a variety of products to choose
