320~360MHz UHF Duplexer Filter for Mobile Radio Repeater

320~360MHz UHF Duplexer Filter used for Mobile Radio field,that is with NF Connector and belong to aaccessory for repeater

Item NO.:
MNF-320~360-NF
Lead Time:
As per your request
Product Orgin:
Anhui,China
Brand:
Maniron
Shipping Port:
Shenzhen,Shnghai
Color:
Black
MOQ:
5

Inquiry now

Products Details

Product Name:

VHF Filter 320~360MHz UHF Duplexer also our popular Passive product,Widely used for in-building Soloution

Product Feature:

♦ Low Insertion Loss

♦ Low VSWR and passive intermodulation

♦ Widely used for in-building Soloution

Technical and Electronic Specifications:

Model No.	MNF-320~360-NF
Frequency range(MHz)	320~360MHz
Power Supply	DC: +12V
Insertion Loss	≤0.6
Gain	≥ 19dB
VSWR	≤ 2
Noise Figure	≤ 1.4dB
Ripple	≤ 2dB
RF Connector	N-Female,IP65
Operating Temperature	-10℃~+55℃

Services:

1. Professional skills support for VHF Filter 320~360MHz UHF Duplexer Filter N-Female Connector for Mobile Radio Repeater
2. OEM services is available.
3. 24 hours you can contact our salesman and engineer.
4. We will try our best to provide support whatever you need and we can do.

NOTE:All the specifications can be changed as customer's requirment. Our company has a variety of products to choose

Detailed Image:

VHF Filter 320~360MHz UHF Duplexer Filter
