100W panel Antenna single-polarization Wall Mounting

Dual band single-polarization Wall Mount antenna Widely used for In-building Solutions,2G/3G/4G/LTE Coverage.
  • Item NO.:

    MN-WA-402-514-NK
  • Lead Time:

    As per the detailed QTY
  • Product Orgin:

    Anhui,China
  • Brand:

    Maniron
  • Shipping Port:

    Shenzhen,Shanghai
  • Color:

    White
  • MOQ:

    5
  • Products Details

Product Name

This type panel Antenna with single-polarization character the installation method is Wall Mount,usually customer purchase 100W single-polarization Wall Mount panel antenna


Product Feature

◆ Wall Mount installation

◆ 2G/3G/4G/LTE Coverage

◆ High Gain with 5-6dBi

◆ Widely used for In-building Solutions


Technical &Mechanical Specifications:

Model No.

                                                 MN-WA-402-514-NK

Frequency Range

                                               402-514/806-866MHz

Gain(dBi)

                                                        5±1dBi

VSWR

                                                       ≤2.0≤1.5

Polarization

                                               vertical polarization

Vertical Beamwidth(0º)

                                                        60±3º

Horizontal Beamwidth(0º)

                                                       75±5º

Front-to-back ratio(dB)

                                                         ≥18

Input Impedance(Ω)

                                                         50Ω

Maximum input power(W)

                                                        100W

Connector type

                                                         N-K

Radome material

                                                        FRP

Installution Method

                                               Wall mounting


Services:

1. Professional skills support forDual band single-polarization Wall Mount antenna 100W 402-514/806-866MHz 5dB
2. OEM services is available.
3. 24 hours you can contact our salesman and engineer.
4. We will try our best to provide support whatever you need and we can do.

NOTE:All the specifications can be changed as customer's requirment. Our company has a variety of products to choose



Horizontal radiation Pattern: Vertical Pattern



Dual band single-polarization Wall Mount antenna


Dual band single-polarization Wall Mount antenna









Dual band single-polarization Wall Mount antenna
