Product Name
700-6000MHz RF Power Tapper with 4.3-10-Female
RF Power Tapper is in Low PIM -161dBc,with Low VSWR and Low Insertion Loss
RF Tapper is widely used for Distributed Antenna System and In-building Solutions,it is waterproof IP65.
Technical &Mechanical Specifications
|
Item |
Specification |
|||||||||
|
Model |
MNPT-340-6000-XX-43F-161 |
|||||||||
|
Frequency Range |
340-960 / 1710-2700 / 3500-4500 / 4900-6000 MHz |
|||||||||
|
Coupling |
3 dB(4.8dB) |
5 dB |
6 dB |
8 dB |
10dB |
13 dB |
15 dB |
20 dB |
30 dB |
|
|
Main I.L(dB) |
340-600MHz |
2.2dB |
2.0 dB |
1.8 dB |
1.3 dB |
1.0 dB |
0.8 dB |
0.6 dB |
0.5 dB |
0.4 dB |
|
Main I.L(dB) |
600-960MHz |
2.3dB |
2.0 dB |
1.9 dB |
1.3 dB |
1.0 dB |
0.8 dB |
0.6 dB |
0.5 dB |
0.4 dB |
|
Main I.L(dB) |
1.71-2.7GHz |
2.4dB |
2.3 dB |
1.9 dB |
1.3 dB |
0.9 dB |
0.8 dB |
0.55 dB |
0.4 dB |
0.4 dB |
|
Main I.L(dB) |
3.5-4.5GHz |
2.6dB |
2.2 dB |
2.0 dB |
1.35 dB |
0.95dB |
0.85dB |
0.6 dB |
0.5 dB |
0.4 dB |
|
Main I.L(dB) |
4.9-6GHz |
2.4dB |
2.2 dB |
2.0 dB |
1.35 dB |
0.95dB |
0.85dB |
0.6 dB |
0.5 dB |
0.4 dB |
|
Coupling Tolerance( dB) |
340-380MHz |
+0/-1.5 |
+0/-1.5 |
+0/-1.5 |
+0/-1.5 |
+0/-1.5 |
+/-1.2 |
+/-1.2 |
+/-1.2 |
+/-1.4 |
|
Coupling Tolerance( dB) |
380-520MHz |
+0/-1.4 |
+0/-1.4 |
+0/-1.3 |
+0.5/-1.2 |
+0.5/-1.0 |
+/-1.0 |
+/-1.0 |
+/-1.0 |
+/-1.4 |
|
Coupling Tolerance( dB) |
600-960MHz |
+/-1.0 |
+/-1.0 |
+/-0.8 |
+/-0.9 |
+/-0.9 |
+/-0.9 |
+/-0.9 |
+/-1.0 |
+/-1.4 |
|
Coupling Tolerance( dB) |
1.71-2.7GHz |
+/-1.2 |
+/-0.9 |
+/-0.9 |
+/-0.9 |
+/-0.9 |
+/-0.9 |
+/-0.8 |
+/-1.2 |
+/-1.4 |
|
Coupling Tolerance( dB) |
3.5-4.5GHz |
+0.7/-1.6 |
+0.5/-1.8 |
+1.0/-1.65 |
+/-1.2 |
+0.5/-1.8 |
+/-1.2 |
+/-1.2 |
+/-1.7 |
+/-1.7 |
|
Coupling Tolerance( dB) |
4.9-6GHz |
+0.7/-1.6 |
+0.5/-1.8 |
+0.8/-1.45 |
+/-1.2 |
+/-1.3 |
+/-1.2 |
+/-1.2 |
+/-1.7 |
+2.2/-2.7 |
|
VSWR |
340-698MHz |
≦1.6 |
≦1.6 |
≦1.6 |
≦1.4 |
≦1.4 |
≦1.4 |
≦1.4 |
≦1.4 |
≦1.4 |
|
VSWR |
698-960MHz |
≦1.5 |
≦1.5 |
≦1.5 |
≦1.4 |
≦1.4 |
≦1.4 |
≦1.4 |
≦1.4 |
≦1.4 |
|
VSWR |
1.710-2.7GHz |
≦1.5 |
≦1.5 |
≦1.5 |
≦1.4 |
≦1.4 |
≦1.4 |
≦1.4 |
≦1.4 |
≦1.4 |
|
VSWR |
3.5-4.5GHz |
≦1.6 |
≦1.6 |
≦1.6 |
≦1.5 |
≦1.5 |
≦1.5 |
≦1.5 |
≦1.5 |
≦1.5 |
|
VSWR |
4.9-6GHz |
≦1.6 |
≦1.6 |
≦1.6 |
≦1.5 |
≦1.5 |
≦1.5 |
≦1.5 |
≦1.5 |
≦1.5 |
|
Intermodulation |
-161dBc@2x43dBm |
|||||||||
|
Power Rating |
300 W |
|||||||||
|
Impedance |
50 Ω |
|||||||||
|
Connector |
4.3-10/Female |
|||||||||
|
Temperature Range |
-35~75ºC |
|||||||||
|
Applications |
Indoor/Outdoor Use , IP67 , RoHS Compliant |
|||||||||
|
Remark |
Install Bracket Include |
|||||||||
|
Product Drawing |
As Below |
|||||||||
