600-2700MHz Low PIM 50W RF Dummy Load

50W Low PIM RF Load Termination covers from frequency 600 to 2700MHz,which is in low VSWR

Item NO.:
YFDL-50W-627-4310F-1
Product Orgin:
China
Brand:
Maniron
Shipping Port:
Shanghai/Shenzhen/Ningbo
Color:
Black

Inquiry now

Products Details

Product Name

50W RF Termination Load with Low PIM,4.3-10-F

Product Features

◆ Wide Frequency Band 600-2700MHz

◆ 2G/3G/4G/LTE Coverage

◆ Low VSWR

◆ Low Passive Intermodulation -161dBc

◆ Widely used for Indoor and outdoor Solutions

RF Load Termination covers freq. 600 to 2700MHz,it has 50w or higher power.It’s widely used for IBS.

Technical &Mechanical Specifications

Frequency	600-2700MHz
VSWR	≤1.20
PIM (dBc)	≤-161dBc@2*43dBm
Average Power(W)	50
Impedance	50Ω
Connector	4.3/10-female
Temp(deg)	-30~+65
Dimension(mm)	166*Ø50(exclude connector)
IP rating	IP67
Weight(kg)	0.95

Note:All specification can be customized according to customers' requirements.

600-2700mhz 50w rf load termination

Our Advantages

Hefei Maniron Electronic And Technology Co.,Ltd.,established in 2002,located in Hefei National Hi-tech Industry Development Zone,is a leading manufacture of RF Components.
OEM services are offered.
Maniron has a huge fellowship that is composed of many high-level technologists.
We also has established a Research Insititution which is a cooperating with some famous universties in China.

varies style, high quality, reasonable price and good service

Excelent engineers and profesional team

Full range of passives for 5G, frequency can be 380-6000MHz

Low PIM -165dBc is also our main advantage
